Vw Fuel Filter Flow Direcrion. Appletree automotive offers a complete line of vw fuel systems fuel filters. These filters have an arrow on them to indicate flow;
Secure the line to the filter with a hose clamp. The filter has two sections, a primary near the top (filters the big particles) and a secondary, finer element in the bottom half. Fuel filter location post by joe2612 » sat mar 26, 2011 7:28 pm just make a note of the fuel flow direction by putting some tape on one of the pipes or something.
